Features 🚀
- Power supply
- Output 48 V / 3.2 A / 150 W
- 2 outputs
- Voltage range 43.2~55.2 V
- DIN rail mount
- 105 (W) x 90 (H) x 55 (D) mm
Specifications 🤓
| Model | DC48V3A-DIN |
| Power supply input | AC 100~240 V / 1.8 A / 50/60 Hz |
| Power supply output | DC 48 V / 3.2 A |
| Voltage range | Adjustable 43.2~55.2 V |
| Maximum output power | 150 W |
| Number of outputs | 2 |
| Temp. operation | -10 ºC ~ +70 ºC |
| Dimensions | 105 (W) x 90 (H) x 55 (D) mm |
| Weight | 540 g |
Package includes 📦
- Power supply
