The Safire SF-IPD934H-4E has a maximum Full HD resolution of 2560x1440 pixels. The camera has a built-in automatic IR cut filter and is a true day/night camera. The camera can enable its built-in IR illumination for clear images in darker conditions. Even in total darkness (0 lux) the camera generates a razor sharp image. The Matrix LED IR have a range of up to 30 meters. The camera features Digital Wide Dynamic Range (DWDR) which gives the camera with the ability to handle complex lighting conditions, due to for example backlight from the sun or car headlights, very well.
Video images can be recorded using a Network Video Recorder (NVR).
Safire offers a free mobile app available for Apple iOS and Android. The camera has an internal web server that can be viewed and managed with a web browser. The latest free Video Management Software (VMS) Safire Control Center for a PC can be downloaded from the Safire website.
The Safire SF-IPD934H-4E has an IP67 rating making the camera ideal for outdoor use. For ease of installation the camera can be powered via the network cable with Power over Ethernet (802.3af POE). PoE can be supplied by the PoE NVR, a switch with PoE or using a PoE injector. The camera can also be powered with an optional 12V power adapter.
Features 🚀
- IP camera
- 1/3" Progressive Scan CMOS
- 4 Megapixel (2560x1440)
- 2.8 mm Lens
- 0 Lux
- IR Range 30 m
- H.265+/H.265/H.264+/H.264
- Dual stream
- IR Cut
- RJ-45 10/100 BaseT
- WEB, CMS, Smartphone and NVR interface
- ONVIF Compatible
- PoE IEEE802.3af
- Weatherproof IP67
| Brand |
SAFIRE |
| Image sensor |
1/3" Progressive Scan CMOS |
| Maximum resolution |
4 Megapixel (2560x1440) |
| Main Stream rate |
20 fps (2560 x 1440, 2304 x 1296, 1920 × 1080, 1280 × 960, 1280×720) |
| Extra Stream rate |
25 fps (640 × 480, 640 × 360, 320 × 240) |
| Compression |
H.265+ / H.264+ / H.265 / H.264 |
| Bitrate |
32 Kbps ~ 8 Mbps |
| Lens |
2.8 mm (H: 100º, V: 55º) |
| Minimum illumination |
0.028Lux F2.0 (color)
|
| Infrared lighting |
0 Lux / IR LEDs (30 m) |
| Image improvements |
BLC, 3D-DNR, DWDR, AWB, ROI, Motion detection, Mirror, Privacy mask |
| Day / Night |
Removable mechanical ICR filter |
| Network interface |
Ethernet 10/100M BaseT |
| Remote access |
Web browser, Safire Control Center Smartphone App and PC Software |
| Interoperability |
ONVIF, PSIA, CGI, ISAPI |
| Lens positioning |
2 Axis |
| Power |
DC 12 V / 300 mA, PoE IEEE802.3af |
| Degree of protection |
Weatherproof IP67, Anti-vandal IK10 |
| Temp. operation |
-30º C ~ +60º C |
| Material |
Metallic |
| Dimensions |
186 (Ø) x 82.4 (h) mm |
| Weight |
400 g |
- Safire IP Dome Camera
- Installation material
- User instructions
- CD with software and instructions
